i just soldered up the LXR and when i was about to do the Step20 test i get no chaselights after what is, i assume a booting process, in which many leds light up and then go off, leaving the VOICE MODE and the first VOICE on. Pressing START only lights up the START LED, but nothing fashes and also the chaselight doesn't start to run.
From reading the forum, i figured that Step23 of the assembly guide should actually happen before the Step20 test, right?!
So i guess i have a problem with the SD card as well, it's a 2GB micro in an adapter formatted as FAT32. But i am not quite sure how the files are supposed to be arranged on the the card. Is it supposed to be like this:
SDCARDIMAGE/ all the files "loose" ( FIRMAWARE.BIN, P000-029.SND, GLO.CFG and README.TXT)
SDCARDIMAGE/SDCardImage (a folder)/ (and there the files: FIRMAWARE.BIN, P000-029.SND, GLO.CFG and README.TXT)
also i haven't soldered the OLED display yet, as i tried to follow the assembly guide step by step...?
Any hints are very welcome. Please hurry!!!
